| Model: QXD-IF680 | Power supply voltage: AC 220V |
| Electrostatic voltage: 40-65KV | Power-off current: ≤50 uA |
| High-voltage power activation: circuit breaker | Applicable paint resistance: 5-50 MΩ |
| Grounding resistance: ≤10Ω | Spray gun weight: 0.86 kg |
The handheld electrostatic liquid spray gun is a professional device that combines high-voltage electrostatic technology with a portable design. It uses high-voltage electricity to negatively charge paint particles, utilizing the principle of electrostatic attraction to precisely apply the paint to grounded workpieces. It is widely used in applications such as automotive repair, furniture painting, industrial parts (such as hardware and plastic parts), agricultural equipment, and architectural decoration. The product combines the flexible operation of a handheld device with the high efficiency and material-saving advantages of electrostatic coating. Compared to traditional spray guns, it improves paint utilization by 50%-80%, resulting in superior coating uniformity. It is suitable for both small-batch precision repairs and efficient coating of medium to large workpieces, making it a core tool that balances environmental protection, efficiency, and coating quality.
| Model: QXD-IF680 | Power supply voltage: AC 220V |
| Electrostatic voltage: 40-65KV | Power-off current: ≤50 uA |
| High-voltage power activation: circuit breaker | Applicable paint resistance: 5-50 MΩ |
| Grounding resistance: ≤10Ω | Spray gun weight: 0.86 kg |
Product Features
1.Electrostatic Adsorption Technology, Material-Saving and Efficient
Equipped with a 40-60 KV high-voltage electrostatic generator, the paint particles are negatively charged after atomization, creating an electrostatic attraction with the grounded workpiece. The paint transfer efficiency reaches 85%-95%, saving over 50% of paint compared to traditional spray guns, significantly reducing paint consumption and environmental treatment costs.
2.Upgraded Fine Atomization, Excellent Coating Texture
Utilizing a dedicated electrostatic atomizing nozzle (stainless steel circular nozzle + adjustable fan-shaped nozzle), combined with the "atomization enhancement" effect of high-voltage static electricity, the atomized particle size is uniform and fine (10-50 μm). The coating is smooth, free of particles and sagging, achieving a flat finish with a single coat, eliminating the need for repeated spraying.
3.Multiple Safety Protections for Worry-Free Use
Built-in high-voltage overcurrent protection and abnormal voltage power-off protection circuits immediately cut off the high voltage and sound an alarm in case of malfunction; the gun body features a leak-proof insulation design, with a power-off current ≤50 uA, eliminating the risk of electric shock.
4.Precise Adjustment, Adapting to Diverse Needs
Spray width (50-300mm), paint flow rate (100-480 mL/min), and spraying pressure (0.25-0.35 MPa) can all be independently adjusted. The spraying distance is 150-250mm, allowing for both narrow-width precise repair and wide-width efficient coating.
